Purification equipment

Air-shower

Fully automatic control, electronic interlocking, double door locking when blowing, automatic blowing by infrared sensor.
User-friendly control panel design, clear indicator light, giving clear airflow process indication. Soft key touch-type time relay;
Stable and reliable running performance, advanced noise reduction and quiet device system and EVA sealing material, high sealing performance.
Product description: The air shower is a highly versatile partial purification device installed between the clean room and the non-clean room. When people and goods enter the clean area, they need to be blown through the
INQUIRY EMAIL

Product statement

The air shower is the necessary passage for people to enter the clean room. It can reduce the pollution problems caused by entering and leaving the clean room, and reduce the large amount of dust particles caused by the ingress and egress of people. Install a fully functional "air lock" from the entrance of the clean room. The room "can reduce the number of air pollution particles. When the goods pass through the air shower, the pollution particles are shot by the highly clean air that is highly filtered. The high wind speed above 25m/s ensures effective spraying and floating particles. Basically filtered out with an efficient two-stage filter. In order to maintain the safe use of the air shower, maintain the cleanliness of the clean room environment.

Technical Parameter

Model Parameter	FLS-1A	FLS-1B	FLS-1C	FLS-3A	FLS-AAS
Application	Single	Single	Single	Three pople	chammel type
Wind cleaning time	0-99s（adjustable）
Spary nozzle number	12（ Two sides）	6（ Two sides）	12（ Two sides）	36（ Two sides）	72（ Two sides）
Jet hole diameter	Φ38mm
Jet hole exportation wind speed	〉20m/s
Filter effciency	≥99.99% (nano flame method) ≤0.5 microns
The area size	700W1x850D1x1900H1	870W1x710D1x1900H1	750W1x700D1x1900H1	700W1x2715D1x1900H1	700W1x4525D1x1900H1
External dimensions	1500Wx950Dx2050H	1100Wx950Dx2050H	1580Wx850Dx2050H	1550Wx2815Dx2050H	5000Wx4625Dx2050H
Power soure	3N,380V,50Hz
Maximum power	800w	400w	1600w	2400w	4800w
Weight	≈300	≈250	≈300	≈600	≈1800
The area size	600x600x120mm
Quamtity	2	1	4	6	12
